DESCRIPTION
Last Thursday’s stream was a set that powered on with a faint whine and no picture. The recording is still being cut, so here is a frame from the bench.
The flyback had a hairline crack that arced under load. A replacement is on order.
What to watch for
- The faint arc visible in the dark.
- How we measure the high-voltage side safely.
- Signs the flyback, not the tube, is at fault.
