DESCRIPTION
This week’s stream was a small portable set that had drifted out of focus. The recording is being edited, so for now here is the frame we grabbed before the adjustments.
The fix itself was simple: a gentle turn of the focus pot on the flyback, then a degauss to clean up the colour purity.
What to watch for
- The focus pot on the flyback and how little it needs to move.
- Purity patches before and after degaussing.
- Why we keep one hand in a pocket near the tube.
