Missing vertical lines on an original Game Boy are almost always a failed bond between the ribbon cable and the glass. The fix is heat, carefully applied along the edge.
The routine
- Lay kapton along the ribbon edge to protect it.
- Slide the iron slowly at about 280 degrees.
- Power it on after every pass to see which lines come back.
Go slower than you think. The glass is older than most of the people fixing it.
Dee Okafor
Too little and nothing happens. Too much and the polariser bubbles. We use a soldering iron with a wide tip and a strip of kapton tape.
