Light guns do not shoot anything. They look for a flash of light at a precise moment in the raster scan, and they rely on the CRT drawing the frame line by line.
How the Zapper decides
- The game blanks the screen and draws white boxes over targets.
- The gun’s photodiode checks for light on the right frame.
- Any processing lag and the hit window is missed.
A light gun is a clock, not a camera. That is why it needs a tube.
Otto Brennan
Modern screens buffer the frame, adding just enough delay that the timing never matches.
