That thunk when a CRT powers on is the degaussing coil firing a decaying alternating field around the tube. It clears stray magnetism from the shadow mask so the colours land where they should.
Using a hand coil
- Remove watches and keep it away from floppy disks.
- Switch it on at arm’s length and move slowly in circles.
- Walk away before switching it off.
Switch off near the screen and you undo all the good work. Walk away first.
Mara Kestrel
When the built-in coil fails, colour patches appear near speakers and magnets. A hand-held coil fixes it in seconds.
